Hongxin 69KV 70FT Hot Dip Galvanized Direct Buried Transmission Steel Pole with Bitumen Anti-Corrosion Painting

جزئیات محصول:

محل منبع: چین
نام تجاری: Hongxin
گواهی: ISO 9001
شماره مدل: HX-70
Document: Company Profile-HX.pdf

پرداخت:

مقدار حداقل تعداد سفارش: 1 تن
قیمت: 800 USD
جزئیات بسته بندی: تحویل برهنه ، بسته بندی کیسه یا پارچه
زمان تحویل: طی 15 روز کاری
شرایط پرداخت: T/T ، L/C
قابلیت ارائه: 1000 تن در ماه
بهترین قیمت مخاطب

اطلاعات تکمیلی
قد: 70 فوت شکل: dodecagonal/ 12sides
مادی: Q355 غلیظ: 5.0 میلی متر
سطح: DIP DIP GALVANISIED / TAR سیاه گالوانیزه ضخیم: به طور متوسط بیش از 86 میکرون
کاربردی: خط انتقال نیرو ضمانت: 5 سال

توضیحات محصول

Hongxin 69KV 70FT Hot Dip Galvanized Direct Buried Transmission Steel Pole with Bitumen Anti-Corrosion Painting


Material


Raw material of general-purpose steel GB/T1591-2008, Q255, Q355, Q420, Q460 used in China.

China-GB

America-ASTM

Equivalent

Q255

Grade D

SS400,S235JO

Q355

Grade50[345]

S355JR

Q420

Grade60[415]

S420NL

Q460

Grade65[450]

S460NL


Manufacturing Process

Our factory owns advanced production lines and machines including two bending calibration machines, hydraulic plate shearing machine, cutting machine, slitting machine, two gas welding machines, hydraulic straightener, etc. All insure us to produce steel poles with best quality.

Hongxin 69KV 70FT Hot Dip Galvanized Direct Buried Transmission Steel Pole with Bitumen Anti-Corrosion Painting 0


Finshed Products


Transmission Pole 50FT 55FT 60FT 65FT 70FT 75FT 80FT 85FT 90FT.

These are non-standard specifications, as we manufacture poles according to  customers’ various requests each time.

Hongxin 69KV 70FT Hot Dip Galvanized Direct Buried Transmission Steel Pole with Bitumen Anti-Corrosion Painting 1

Steel Pole of National Electrification Administration

(PHILIPPINES)

Specification for Distribution Steel Pole 25FT, 30FT, 35FT, 40FT,45FT.

Height

(ft)

Thickness

(mm)

Butt Diameter

(mm)

Top

Diameter

(mm)

Design

Load

(kg)

Yield

Stress

(MPA)

Zinc

Coating

(microns)

25

2.5

152

120

300

345

86

30

3.0

226

127

500

345

86

35

3.0

248

127

500

345

86

40

3.0

317

127

500

345

86

45

4.0

328

127

750

345

86


Inspection
To ensure the quality, we have professional engineers to inspect the poles during the manufacturing and before delivery.
We have Lab Test, Workload Test, Steel thickness Test, Galvanization thickness Test, etc.


Delivery
We normally use 40HQ containers and our Port limit weight for a 40HQ is 26 tons.


FAQ

1. Are you a manufacturer or a trading company?
A:We are the direct factory manufacturer and the trading company.

2. Where is your company located?
A:Our factory is located in Yinhe Road No.3, Wanshi town, Jiangsu, China(mainland).

3. What are your main products?
A:Our main products are electric poles, street lighting poles, high mast pole, telecommunication tower poles, traffic signal poles, wind generation poles, etc.

4. What's your nearest port?
A: Shanghai Port is our nearest port.

5. What's your payment term?
A: Normally 30% deposit and rest by TT before shipping. Or L/C.

6. What's your delivery time?
A: Normally within 15 working days. If our factory is busy and your quantity is large, then around one month.

7. What's your price term?
A: Price Term: EXW, FOB, CFR or CIF.
EXW: Poles Cost
FOB: Pole Cost + Land Transportation + Fee on Port
CFR: Pole Cost + Land Transportation + Fee on Port + Sea Freight
CIF: Pole Cost + Land Transportation + Fee on Port + Sea Freight + Insurance.

Hongxin 69KV 70FT Hot Dip Galvanized Direct Buried Transmission Steel Pole with Bitumen Anti-Corrosion Painting 2
